Keeping your drinks cold and your food fresh is no problem for Coyote Outdoor Living’s outdoor refrigeration products. Coyote’s Outdoor Refrigerator performs as great as it looks. Having a refrigerator as part of your space can also reduce the need to go back and forth from an indoor kitchen – meaning more time to enjoy the outdoors with your family and friends

What’s Included

• 1 x Control Panel Sticker
• 1 x Temperature control box
• 1 x Light
• 1 x Air Deflector
• 1 x Cooling Fan
• 3 x Upper Shelf
• 1 x Lower Shelf
• 4 x Leveling Leg
• 1 x Venting Grid
• 1 x Lock
• 1 x Door
• 1 x Door Handle
• 1 x Top Hinge

Not Included (Sold Separately)

• Trim Kit

Features

• Coyote professional style handle
• Exterior constructed with 304 stainless steel
• Hidden, articulating hinges for flush installation
• Front Vented For Built-In Application
• Stainless steel cabinet construction
• Graphite interior with interior LED lighting
• Adjustable digital thermostat for precision temperature control
• Standard lock
• Automatic defrost
• Stainless steel shelving
• Outdoor Rated
• UL Certified
• DOE Certified

Specifications

Item Number	C1BIR24-R
UPC	653341106407
Brand Name	Coyote Outdoor Living
Hinge	Right
Capacity	5.5 cu. ft.
Rated Voltage	115V AC
Amps	2
Hz	60
Refrigerant	R600a/1.06Oz
Power Input	100 W
High Side Pressure	270 PSI
Low Side Pressure	103 PSI
Cutout Dimensions	23 3/4″ (W) x 22 3/4″ (D) x 33 1/4″ (H)
Overall Dimensions	23 1/2″ (W) x 22 1/2″ (D) x 33″ (H)

Technical Drawings & Dimensions

Cutout Dimensions

Overall Dimensions

Warranty

1 Year Limited Warranty on ALL Parts

Documents & Files

• Coyote Outdoor Living Catalog
• Owner’s Manual
• Install Guide
• Trim Kit Install Guide
