The Broilmaster Story
Historically, Broilmaster’s cast-aluminum grill head featured a deep bottom casting that allowed more uniform temperature across the cooking grid. The original Broilmaster G-1000 also featured the now legendary Bow Tie Burner, known for even heat distribution. Variations of both can be found on most modern Broilmaster grills.
Throughout the years Broilmaster expanded the cast-aluminum offerings to include a full line up of gas, infrared, and charcoal grills. Each Broilmaster grill incorporates a variety of features such as multi-level cooking grids, retract-a-rack, separate burner controls, stainless steel griddles, and the patented Smoker Shutter.
In 2018 we introduced the Broilmaster Stainless gas grill series. Broilmaster Stainless gas grills combine the distinctive features of an original Broilmaster with a sleek, contemporary design. The versatile multi-level cooking grids, retract-a-rack, and timeless Bow Tie Burner live on in this new generation of stainless steel grills.
With the combination of versatile cooking capabilities, convenient features, and unmatched customer service, a Broilmaster grill is truly the grill of a lifetime.
Description
The Broilmaster Charcoal C3 grill features a large cast aluminum grill head which heats quickly and evenly, helping you maintain a consistent cooking temperature. Up to 442 sq. inches of total cooking area and adjustable cooking grids give you the freedom to tackle any size meal.
Twin air intakes on the front panel and a rotary dual-function top vent adjust from wide open to fully closed – allowing precise control of temperature and smoke. The two front-loading doors let you add charcoal or wood chunks without removing the cooking grids.
Standard Features
Heavy-Duty Cast Aluminum ConstructionDesigned To Last and Maintain Cooking Temperature |
|
Multi Level Stainless Steel Cooking GridsProvide Control Over Food Distance To The Flame |
|
|
|
Stainless Steel Oval Burner
|
|
|
|
Removable Ash Pan
|
Other Features
- 442 sq. in. of total cooking area
- Heavy-duty cast aluminum construction
- Left and right air intake on front panel
- Rotary, dual function smoke vent on lid
- Front-access tilt open doors for loading charcoal and emptying slide out ash tray
Technical Specifications
| Fuel Type: | Charcoal |
| Total Grilling Area | up to 442 Sq. Inches |
| Color: | Black |
| Item Weight: | 81 lbs. |
| Overall Head Dimension: | W 26 3/4″ x H 20 1/2″ x D 18 3/4″ |
| Cooking Grid Material: | Stainless Steel |
| External Material: | Cast Aluminum |
C3 Built-In Includes:
- Two Stainless Steel Rod Cooking Grids – 3-Level Adjustable (695 Sq. In. of Total Cooking Area)
- Stainless Steel Ash Pan – Front Loading
- Stainless Steel Load Door lets you add charcioal without removing cooking grids
- Twin Air Intakes on Front and Rotary Dual-Function Top Vent for precise temperature control
- Stainless Steel Built-In Kit
BROILMASTER WARRANTY | |
| LIMITED LIFETIME Against Rust-through | Aluminum Grill Housing (except paint), Stainless Steel Cooking Grids and Stainless Steel Griddles, Select Stainless Steel Components – Cart, Mounting, Bow Tie Burner, Side Burner (DPA150), Side Burner (DPA151), Side Shelf (DPA153), and Warming Rack, Stainless Steel Built-In Components – Built-In Kits for 3-Series Grill Heads, Side Burner Surround (DPA152), Door Kit, Tilt-Out LP Tank Door, and Vent Register Kit |
| 10 YEARS Against Rust-through | Stainless Steel Burners for H-Series and R3B |
| 5 YEARS Against Rust-through | Infrared Burners on R3 and R3B, and Side Burner (DPA151), Flare Busterâ„¢ Ceramic Flavor Enhancer , Painted Electro-Galvanized Steel Components, Stainless Steel Smoker Shutter |
| 2 YEARS Against Rust-through | Porcelain Coated Steel Briquet Racks, Chrome-Plated Warming Rack, Stainless Steel Flavor Screen, Stainless Steel Heat Shield |
| 1 YEAR Against Rust-through | Valves, knobs, ignitors, labels, hoses, fittings, grease cups, drip buckets, and all other parts and accessories – including those made from stainless steel – unless specified above, paint on aluminum grill head |
Options and Accessories
Click to see Island Accessories
|
BDA Built-In Stainless Steel Single Door Kit
|
|
|
BBA Built-In Stainless Steel Tilt-Out Tank Door
|
|
|
BRB Built-In Stainless Steel Register Kit
|
|
|
BRB Built-In Stainless Steel Register Kit
|
Click to see Other Accessories
|
Stainless Steel Griddle From bacon, eggs, and pancakes to cookies, this super-duty griddle adds versatility to your Broilmaster grill. Made from thick stainless steel, the griddle includes a large cooking surface and drip tray. |
|
|
Diamond Cooking Grids These diamond-patterned cooking girds are easy to cook on and clean, making them the perfect solution for cooking your fish and vegetables. |
|
|
Broilmaster Stainless Steel Retrack-A-Rack Warming Rack The folding stainless steel retract-a-rack attaches to your Broilmaster grill in minutes to add 253 square inches of cooking area to your grill. The unique design automatically retracts when you lift the grill lid, giving you easy access to the main cooking grids. |
|
|
DPA301 Ceramic Glass Infrared Panel The ceramic glass infrared panel installs beneath a cooking grid to turn high heat from the Broilmaster Charcoal grill into infrared energy to sear. The durable stainless steel and ceramic glass panel are dishwasher safe. |
|
|
DPA304 Firebox Divider Plate The firebox divider plate separates the charcoal area of your Broilmaster charcoal grill so you can cook on just one side, indirect cook, or use the independent air intake system to create a temperature differential inside your grill. The 12-gauge stainless steel construction provides durability to ensure a long life. |
|
|
DPP307 Door Gasket Set for C3 Charcoal Grill
|
|
|
DPP308 Lid Gasket for C3 Charcoal Grill
|
|
|
Broilmaster DPA306 Ash Tool For C3 This ash tool reaches safely into the far corners of your charcoal grill to add or reposition charcoal and wood chips, and to remove ashes. Features:
|
Downloads
- C3 Charcoal Grill Manual
- Broilmaster Brochure
- Built-In Owner’s Manual
