Features

System

• 55,000 BTU main burner output
• 10,000 BTU Infrared Side Burner
• 15,000 BTU stainless steel rear rotisserie burner and premium rotisserie kit
• 875 sq. in. / 5,645 sq. cm. total cooking space including porcelain-coated warming rack
• 625 sq. in. / 4,032 sq. cm. primary cooking space
• Solid 9mm stainless steel cooking grids
• Stainless steel Flav-R-Wave™ cooking system
• Five stainless steel Dual-Tube™ burners
• Linear-Flow™ valves with 180° sensi-touch™ control
• Sure-lite™ electronic dual-electrode ignition system
• Deluxe Accu-Temp™ thermometer

Design

• Stainless steel hood panel with rugged cast aluminum end caps
• Stainless steel cookbox with cast aluminium end caps
• Stainless steel shelves with cast aluminium condiment bins
• Enclosed cabinet with stainless steel cabinet doors
• Stainless steel control panel
• Pull-out tank drawer (LP model)
• Built-in control panel lights
• Heavy-duty locking swivel casters with level setting

Fuel Options

• Natural Gas (NG) – 10ft natural gas hose included.
• Propane (LP) – designed for use with 20lb tank – not included.

Specifications

Item Number	BK688247
Model	Q Regal 590 Pro IR
Fuel Type	Natural Gas
No. of Burners	5
Main Burner Output	50,000 BTU
Infrared Burner	10,000 BTU
Rotisserie Burner	15,000 BTU
Primary Cooking Space	625 SQ. IN.
Dimensions	49.2″ (H) x 62.5″ (W) x 24.8″ (D)
Weight	217.0 lbs (LP Model)

Warranty

We reward quality. This Broil King® features a Limited Lifetime Warranty on the entire cookbox, 15 years on Dual-Tube™ burner system, and 15 years top to bottom, on all remaining parts and paint.

Documents & Files

• Assembly Manual
• Owner’s Manual
